Cablelok S15M5 6.8-7.2mm x10
Art.-No. 857-50229
| CABLELOK-S15M5-10
|
Details
- Cable range 6.8mm to 7.2mm
- Allows 5 cables drops from a single S Port
- Supplied in multiples of 1 and 10
- Supplied with installation lubricant sachets
More products in this product group:
Cable ∅ max | 7.2mm |
Cable ∅ min | 6.8mm |
Colour | Black (BK) |
Description | HellermannTyton’s patented Cablelok mechanical seal enables fast safe cable installation, providing a highly repeatable and consistent seal between the cable and the closure port with excellent non-leak performance. Tested to in excess of 6m head of water, the Cablelok does not rely on the skill and experience of the engineer to achieve the required seal, whilst installation times are typically reduced by up to 90%. |
Material | Chloroprene Rubber (CR) |
PART DESCRIPTION | CABLELOK-S15M5-10 |
Pack Cont. | 10pcs. |
Package Content packed in | bag |
Port | S |
Port count | 5 |
Product Family | Cablelok |
Product Group | S Port Multi-Drop Cablelok |
Short Description | Cablelok S15M5 6.8-7.2mm x10 |
Technical Description | The S Port Multi-Drop Cablelok is a meachnical seal manufactured from Polychloropene. This cablelok fits in to a single S Port on the HellermannTyton closures converting it from a single cable drop port to a 5 cable drop port for cables with a diameter range of 6.8mm - 7.2mm |
Type | CABLELOK-S15M5-10 |
