Bundling clip for hole (round), L=45.0mm, SO=20.3mm, natural, 2000pcs.
Art.-No. 133-01497 | SOC14FT6-PA66HIRHS-NA

Copied
  • Clip can be installed by hand – no need for hardware or tools.
  • Design provides low insertion and high extraction force, for simple, secure performance.
  • Clip keeps bundle away from areas that could cause damage due to rubbing.

Request your individual offer now

Application Standoff bundling clips provide a straightforward way to secure cable bundles, hoses or pipes. The bundle fastens to the tape bar using tape or cable ties. Multiple orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standoff keeps bundles away from mounting area to prevent them from damage due to rubbing.
Colour Natural (NA)
Fixation Method Fir Tree
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION SOC14FT6-PA66HIRHS-NA
Pack Content 2000pcs.
Package Content packed in pack
Type SOC14FT6
Bundling Bar Length 45.0mm
Length (L) 45.0mm
Offset Length 20.3mm
Panel Thickness 0.02 - 0.24"
Panel Thickness max. 0.6 - 6.0mm
Panel Thickness max. (imperial) 0.24"
Panel Thickness min. (imperial) 0.02"
for Hole ⌀ (FH) 6.1 - 6.9 mm
for Panel Thickness min - max 0.6 - 6 mm
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised No
GTIN-13 / EAN 4031026482569
Packaging 1 - Height (m) 0.127m
Packaging 1 - Length (m) 0.508m
Packaging 1 - Qty 2000
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.019612864
Packaging 1 - Weight (kg) 3.780001kg
Packaging 1 - Width (m) 0.304m
Packaging 3 - Height (m) 0.1397m
Packaging 3 - Length (m) 0.51276m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0223
Packaging 3 - Weight (kg) 4.45kg
Packaging 3 - Width (m) 0.31115m
Packaging 4 - Height (m) 0.895m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 56000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 0.859
Packaging 4 - Weight (kg) 140.84kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121702
