Bundling clip for edge, SO=5.8mm, black, 2000pcs.
Art.-No. 133-04368 | TBC85-PP/MET-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Fixation Method Edge Clip
    Material Polypropylene (PP), Metal (MET)
    PART DESCRIPTION TBC85-PP/MET-BK
    Pack Content 2000pcs.
    Package Content packed in bag
    Type TBC85
    Bundle Diameter max (metric) 6.1mm
    Diameter (D) 3.0mm
    Height (H) 16mm
    Length (L) 10.9mm
    Length (L2) 54.1mm
    Offset Length 5.8mm
    Panel Thickness 0.08 - 0.11"
    Panel Thickness max. 2.1 - 2.9mm
    Panel Thickness max. (imperial) 0.11"
    Panel Thickness min. (imperial) 0.08"
    Width (W) 15.2mm
    Width (W2) 0.6"
    Width (W2) 15.3mm
    for Panel Thickness min - max 2.1 - 2.9 mm
    ∅ D 0.12"
    CE Certification No
    CSA Certified No
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 4031026715063
    Packaging 3 - Height (m) 0.1603502m
    Packaging 3 - Length (m) 0.5159502m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0282m³
    Packaging 3 - Width (m) 0.3413252m
    UNSPSC Key 39121702
