LPC0380-PVC-BK
Art.-No. 166-90247 | LPC0380-PVC-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Material Polyvinylchloride (PVC)
    PART DESCRIPTION LPC0380-PVC-BK
    Pack Content 30.5m
    Package Content packed in reel
    Type LPC0380
    Bending Radius min. (BR) 1.97"
    Bending Radius min. (R) 50mm
    Inner Diameter D (Imperial) 0.47"
    Inside Ø (ID) 12mm
    Length (L) 30.5m
    Nominal ∅ 0.38"
    Nominal ∅ 16mm
    Outside Ø (OD) 17.8mm
    Outside ∅ (OD) 0.70"
    CSA Certified No
    Flammability EN IEC 61386-1
    Halogen-free No
    Operating Temperature -5 °C to +70 °C
    ROHS compliant Yes
    Self extinguishing Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    GTIN-13 / EAN 4031026485041
    UNSPSC Key 39131601
    Cable protection conduits Cable protection conduits

    Cable Protection Conduits

    Perfect cable protection with flexible conduits and fittings, braided sleeving, spiral binding and cable protection tubing ...
