Cable tie mount for screw fixation, Wmax=5.0mm, ∅4.3 mm, M4 Screw, natural, 100pcs.
Art.-No. 151-00539
| CTAM1-PA66-NA
|
세부
- Suitable for applications with minimal space
- Mounted before cable installation and in line with cable
- CTAM has 4-way entry design for use in line or at 90° angle to cable run
More products in this product group:
| Application | Each of these products offers particular benefits, but all are designed for simple yet robust installation in a wide variety of applications. Particularly used in telecoms equipment, switchgear and control cabinets these cable tie mounts are also used within the aerospace and railway industry. |
| Colour | Natural (NA) |
| Fixation Method | Screw Mounting and Rivet |
| For Ties | T18 - T50 |
| Material | Polyamide 6.6 (PA66) |
| Mounting Screw Type | M4 Screw |
| PART DESCRIPTION | CTAM1-PA66-NA |
| Pack Content | 100pcs. |
| Package Content packed in | bag |
| Product Family | CTAM-Series for applications where space is limited |
| Product Group | Screw fixing mounts |
| Type | CTAM1 |
다운로드
| Flammability | UL 94 V2 |
| Operating Temperature | -40 °C to +85 °C |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | ANSI/UL 1565, ANSI/UL 62275 |
| UL OCD link | Link |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | E64962 |
