Cable tie mount with pipe/tube holder, ∅8.2 mm, green, 600pcs.
Art.-No. 151-03254 | HDCM2B-PA66GF15-GN | 세부

Separates and secures bundles or convoluted tubing to prevent abrasion.

Base Data

Colour	Green (GN)
Key product features	for multiple routing, releasable
Material	Polyamide 6.6, glass-fibre reinforced (PA66GF15)
PART DESCRIPTION	HDCM2B-PA66GF15-GN
Pack Content	600pcs.
Package Content packed in	bag
Type	HDCM2B
Variant	Separators

Product Dimensions

Bundle Diameter max (metric)	17.20mm
Bundle ∅ min.	17.20mm
Height (H)	34mm
Length (L)	69.1mm
Width (W)	28.48mm
for Hole ∅ (FH)	8.2 mm
∅ max. 1. loop	17.20mm
∅ max. 2. loops	17.20mm

Downloads

RoHS datasheet

다운로드

Specifications

CE Certification	No
CSA Certified	No
Operating Temperature	-40 °C to +125 °C
ROHS compliant	Yes
Specifications
UV-Stabilised	No

Logistics and Packaging

GTIN-13 / EAN	4031026646565
Packaging 1 - Qty	600
Packaging 1 - Type	box

More Information

UNSPSC Key

39121717
