Cable tie mount for adhesive use, Wmax=3.6mm, ∅3.0 mm, Adhesive, black, 500pcs.
Art.-No. 151-01630 | MB3A4-PA66HIRHSUV-BK 세부

  • Simple to instal
  • Excellent security, particularly in areas of high vibration
  • Maximum surface area with adhesive to achieve high pull-off force
  • 4-way entry for cable tie for quicker and more flexible installation
Application Mount will adhere to medium and high surface energy paints, as well as a wide range of plastics commonly found in the automotive, heavy truck/equipment industries.
Colour Black (BK)
Fixation Method adhesive
For Ties T18 - T30
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Maximum Static Load (lb/ft) 0.6lbf-ft
Mounting Screw Type Adhesive
PART DESCRIPTION MB3A4-PA66HIRHSUV-BK
Pack Content 500pcs.
Package Content packed in bag
Product Family MB-Series square design, self-adhesive
Product Group Cable tie mounts
Type MB3A4
Fixing Hole Centres (F) 0.52"
Fixing Hole Centres (F) 13.2mm
Height (H) 4.8mm
Length (L) 19.0mm
Load max. 2.669N
Max. Tie Width (G) 3.6mm
Strap Width max. (G) 0.14"
Width (W) 19.0mm
for Hole ∅ (FH) 3.0 mm
Adhesive Acrylic foam
Adhesive Operating Temperature -40 °C to +80 °C
CE Certification No
CSA Certified No
Flammability UL 94 HB (excluding adhesive)
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised Yes
GTIN-13 / EAN 4031026565804
Packaging 3 - Height (m) 0.212725m
Packaging 3 - Length (m) 0.51435m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0347
Packaging 3 - Width (m) 0.3175m
UNSPSC Key 39121717
