Cable tie inside serrated, 387x7.6mm, ∅5-105mm, natural, 50pcs.
Art.-No. 111-00581 | T120R-PA46-NA 세부

  • Cable tie for high temperature applications up to +150 °C (5000 h) and +195 °C (500 h)
  • Available in different sizes to cover various bundle diameters
  • Low smoke generation in the event of a fire
  • PA46 is a moisture sensitive material
  • Inside serrated cable tie offers strong hold around bundles
  • Easy application either manually or with an application tool
  • Operating temperature (long-term) up to +130 °C
Show more
Application These inside serrated cable ties are made from Polyamide 4.6 (PA46). They can be applied in environments with temperatures up to +195 °C (for 500 hours) which makes them suitable for applications where a broader temperature range is required. Polyamide 4.6 is a well-known material in the automotive, railway or white goods area. An application tool is recommended to ensure greater process reliability while installing cable ties.
Colour Natural (NA)
Identification Plate Position none
Material Polyamide 4.6 (PA46)
PART DESCRIPTION T120R-PA46-NA
Pack Content 50pcs.
Product Family T-Series in PA46
Product Group Cable Ties for temperatures up to + 195 °C (500 h) in Polyamide 4.6
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T120R
Variant Inside Serrated
Bundle Diameter max (metric) 105mm
Bundle ∅ min. 5mm
Cable Tie Head Length (metric) 10.5mm
Cable Tie Head Width (metric) 12.65mm
Height (H) 7.35mm
Length (L) 387mm
Min.Tensile Strength 535N
Strap Width max. (G) 0.50"
Thickness (T) 1.9mm
Width (W) 7.6mm
Flammability UL 94 V2
Limited Fire Hazard Yes
Operating Temperature -40 °C to +130 °C, (+150 °C, 5000 h; +195 °C, 500 h)
ROHS compliant Yes
Specifications
UL-File Number E193818
UV-Stabilised No
UNSPSC Key 39121703
