Fixing tie for hole (oval), inside serrated, ∅1.5-45.0mm, black, 500pcs.
Art.-No. 156-00641
| COW30T50R-PA66/PA66HS-BK
|
세부
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust, dirt and water
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
- DOP versions for oval holes feature anti-twist protection
More products in this product group:
Application | Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines. |
Cable Tie | Polyamide 6.6 (PA66) |
Colour | Black (BK) |
Fixation Method | Fir Tree |
Identification Plate Position | none |
Material | Polyamide 6.6 (PA66), Polyamide 6.6, heat stabilised (PA66HS) |
PART DESCRIPTION | COW30T50R-PA66/PA66HS-BK |
Pack Content | 500pcs. |
Package Content packed in | bag |
Product Family | 2-Pieces Fixing Ties with Fir Tree, with Disc, for Oval Holes |
Product Group | 2-Pieces Fixing Ties with Fir Tree, with Disc |
Tie Closure | plastic pawl |
Type | COW30T50R |
Variant | Inside Serrated |
Bundle Diameter max (metric) | 45.0mm |
Bundle ∅ min. | 1.5mm |
Cable Tie Head Height (metric) | 5.8mm |
Cable Tie Head Length (metric) | 7.3mm |
Cable Tie Head Width (metric) | 7.8mm |
Disc ∅ | 16.0mm |
Height (H) | 1.2mm |
Height (H2) | 6.6mm |
Length (L) | 202.0mm |
Length (L2) | 30mm |
Min.Tensile Strength | 225N |
Width (W) | 4.6mm |
Width (W2) | 42.0mm |
for Hole ∅ (FH) | 6.3 - 7.0 mm |
for Panel Thickness min - max | 0.8 - 4.5 mm |
