22/11/2024

Fixing tie for edge, inside serrated, ∅1.0-20.0mm, black, 7000pcs.
Art.-No. 156-00180 | T18REC22SET-PA66HS/PA66HIRHS-BK 세부

Colour Black (BK)
Content 3000 T18R + 3000 EC22
Fixation Method Edge Clip
Identification Plate Position none
Key product features for narrow bundling
Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T18REC22SET-PA66HS/PA66HIRHS-BK
Pack Content 7000pcs.
Package Content packed in box
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T18REC22SET
Variant Inside Serrated
Bundle Diameter max (metric) 20.0mm
Bundle ∅ min. 1.0mm
Height (H) 1.0mm
Height (H2) 12.5mm
Length (L) 100.0mm
Length (L2) 15.0mm
Min.Tensile Strength 80N
Panel Thickness max. (imperial) 0.12"
Panel Thickness min. (imperial) 0.4"
Width (W) 2.45mm
Width (W2) 0.3"
Width (W2) 9.2mm
for Panel Thickness min - max 1 - 3 mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026267401
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 7000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 13.95kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 140000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 300.0kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121717
