Fixing tie to close hole, ∅2.5-50.0mm, black, 500pcs.
Art.-No. 156-01726 | T50RBHMB-PA66HS-BK 세부

Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
Colour Black (BK)
Fixation Method Blind Plug
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION T50RBHMB-PA66HS-BK
Pack Content 500pcs.
Package Content packed in bag
Type T50RBHMB
Bundle Diameter max (metric) 50.0mm
Bundle ∅ min. 2.5mm
Diameter (D) 6.35mm
Height (H) 18.7mm
Height (H2) 12.4mm
Hole Depth 12.7mm
Length (L) 203.2mm
Min.Tensile Strength 225N
Width (W) 7.8mm
for Hole ∅ (FH) 6.25 - 6.45 mm
∅ D 0.25"
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +125 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
GTIN-13 / EAN 4031026581255
Packaging 1 - Qty 500
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 3.315001kg
Packaging 3 - Height (m) 0.37668199999999996m
Packaging 3 - Length (m) 0.5902959999999999m
Packaging 3 - Qty 500
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0635
Packaging 3 - Weight (kg) 9.19kg
Packaging 3 - Width (m) 0.285496m
Packaging 4 - Height (m) 1.276m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 6000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.225
Packaging 4 - Weight (kg) 70.98kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121703
