Fixing tie with pipe/tube holder, inside serrated, ∅20.0-25.0mm, black, 1000pcs.
Art.-No. 156-01820 | T50RMOC22SAD-SET-PA66HIRHSUV-BK 세부

Cable ∅ max 50.0mm
Cable ∅ min 1.5mm
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features for multiple routing, removable
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION T50RMOC22SAD-SET-PA66HIRHSUV-BK
Pack Content 1000pcs.
Package Content packed in carton
Product Group 2-Piece Fixing Ties with Pipe Clip
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50RMOC22SAD-SET
Variant Inside Serrated
Bundle Diameter Nom. (ND) 22.0 mm
Bundle Diameter max (metric) 25.0mm
Bundle ∅ min. 20.0mm
Depth (D) 12.0mm
Height (H) 42.6mm
Length (L) 30.5mm
Length (L2) 21.2mm
Min.Tensile Strength 225N
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised Yes
GTIN-13 / EAN 4031026592794
Packaging 3 - Height (m) 0.212725m
Packaging 3 - Length (m) 0.51435m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0347
Packaging 3 - Width (m) 0.3175m
UNSPSC Key 39121702
