Fixing tie with pipe/tube holder, inside serrated, ∅4.0-5.5mm, black, 2000pcs.
Art.-No. 156-01811 | T50RMOC5SAD-SET-PA66HIRHSUV-BK 세부

Cable ∅ max 50.0mm
Cable ∅ min 1.5mm
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features removable, for multiple routing
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION T50RMOC5SAD-SET-PA66HIRHSUV-BK
Pack Content 2000pcs.
Package Content packed in carton
Product Group 2-Piece Fixing Ties with Pipe Clip
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50RMOC5SAD-SET
Variant Inside Serrated
Bundle Diameter Nom. (ND) 5.0 mm
Bundle Diameter max (metric) 5.5mm
Bundle ∅ min. 4.0mm
Depth (D) 10.0mm
Height (H) 17.0mm
Length (L) 8.3mm
Length (L2) 11.0mm
Min.Tensile Strength 225N
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free Yes
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised Yes
GTIN-13 / EAN 4031026592343
Packaging 1 - Qty 2000
Packaging 1 - Weight (kg) 200.55kg
Packaging 3 - Height (m) 0.212725m
Packaging 3 - Length (m) 0.51435m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0347
Packaging 3 - Width (m) 0.3175m
UNSPSC Key 39121702
