Fixing tie for hole (oval), outside serrated, ∅2.0-50.0mm, black, 1000pcs.
Art.-No. 157-00247 | T50ROSFTOVAL25B-PA66HIRHS-BK | 세부

Bundling and fixing solution
Ideal combination of materials and design
Different positions of the fixing anchor are available to fit installation space
1-Piece Fixing Tie with defined offset 12.5 and 25.0 mm

More products in this product group:

Colour	Black (BK)
Fixation Method	Fir Tree for oval holes
Identification Plate Position	none
Material	Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION	T50ROSFTOVAL25B-PA66HIRHS-BK
Pack Content	1000pcs.
Package Content packed in	bag
Product Family	with offset 12.5 and 25.0 mm
Product Group	1-piece fixing ties with fir tree, with disc, with stand-off, for oval holes
Releasable Closure (Yes/No)	No
Type	T50ROSFTOVAL25B
Variant	Outside Serrated

Bundle Diameter max (metric)	50.0mm
Bundle ∅ min.	2.0mm
Disc ∅	17.63 x 23.63mm
Disc ∅	0.69 x 0.93"
Fixing Hole Shape	Oval
Height (H)	13.15mm
Length (L)	229.3mm
Length (L2)	25.0mm
Min.Tensile Strength	225N
Offset Length	25.04mm
Panel Thickness	0.02 - 0.27"
Panel Thickness max.	0.6 - 6.75mm
Panel Thickness max. (imperial)	0.27"
Panel Thickness min. (imperial)	0.02"
Thickness (T)	1.35mm
Width (W)	4.70mm
for Hole ∅ (FH)	6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
for Panel Thickness min - max	0 - 0.3 "
for Panel Thickness min - max	0.6 - 6.8 mm
