Fixing tie for stud, ∅2.0-50.0mm, brown, 3000pcs.
Art.-No. 157-00338 | T50ROSLPM6SMSO25-PA46-BN 세부

  • One-piece fixing ties
  • High specification materials
  • Superior design
  • Suitable for complex applications
Application Primarily designed for use in the automotive industry, these parts can be used in a wide variety of applications where weld studs or ISO bolts are used and cables need to be bundled and secured.
Colour Brown (BN)
Fixation Method Stud Mount
Identification Plate Position none
Material Polyamide 4.6 (PA46)
PART DESCRIPTION T50ROSLPM6SMSO25-PA46-BN
Pack Content 3000pcs.
Package Content packed in carton
Product Group 1-Piece Fixing Ties for Weld Studs
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50ROSLPM6SMSO25
Bundle Diameter max (metric) 50.0mm
Bundle ∅ min. 2.0mm
Height (H) 6.30mm
Length (L) 223.52mm
Min.Tensile Strength 225N
Offset Length 25.5mm
Stud ∅ 0.20 ", 0.24"
Stud ∅ 5.0 mm, 6.0 mm
Width (W) 14.2mm
for Hole ∅ (FH) M6 x 1
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +130 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
GTIN-13 / EAN 4031026702094
Packaging 1 - Qty 3000
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 7.260001kg
Packaging 3 - Height (m) 0.2159m
Packaging 3 - Length (m) 0.606425m
Packaging 3 - Qty 3000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.052
Packaging 3 - Weight (kg) 7.99kg
Packaging 3 - Width (m) 0.396875m
Packaging 4 - Height (m) 1.269m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 36000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.218
Packaging 4 - Weight (kg) 116.88kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121703
