Fixing tie with pipe/tube holder, ∅2.0-50.0mm, black, 250pcs.
Art.-No. 156-02527 | T50SMVCOC25-31-PA66HIRHSUV/PA66HIRHS-BK | 세부

T50SVCOC/T50SMVCOC

More products in this product group:

2-Piece Fixing Ties with Pipe Clip, twistable 360° >

Base Data

Colour	Black (BK)
Fixation Method	Omega Clip
Identification Plate Position	none
Key product features	rotatable, for multiple routing, removable
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION	T50SMVCOC25-31-PA66HIRHSUV/PA66HIRHS-BK
Pack Content	250pcs.
Package Content packed in	bag
Product Group	2-Piece Fixing Ties with Pipe Clip, twistable 360°
Type	T50SMVCOC25-31

Product Dimensions

Attach to Diameter	0.98 - 1.22 "
Attach to Ø	25.0 - 31.0
Bundle Diameter max (metric)	50.0mm
Bundle ∅ min.	2.0mm
Length (L)	210.0mm
Min.Tensile Strength	222N
Thickness (T)	1.35mm
Width (W)	4.7mm

Downloads

Specifications

Operating Temperature	-40 °C to +85 °C
ROHS compliant	Yes
Specifications
UV-Stabilised	Yes

Logistics and Packaging

GTIN-13 / EAN	4031026765242
Packaging 3 - Type	box
Packaging 3 - Weight (kg)	7.03kg

More Information

UNSPSC Key

39121702
