17/07/2024

Fixing tie to close hole, outside serrated, ∅2.5-35.0mm, black, 500pcs.
Art.-No. 156-01807 | T50SOSBHMB-PA66HS-BK 세부

Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
Colour Black (BK)
Fixation Method Blind Plug
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION T50SOSBHMB-PA66HS-BK
Pack Content 500pcs.
Package Content packed in bag
Type T50SOSBHMB
Bundle Diameter max (metric) 35.0mm
Bundle ∅ min. 2.5mm
Diameter (D) 6.35mm
Height (H) 18.7mm
Height (H2) 12.4mm
Hole Depth 12.7mm
Length (L) 150.0mm
Min.Tensile Strength 225N
Width (W) 7.8mm
for Hole ∅ (FH) 6.25 - 6.45 mm
∅ D 0.25"
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +125 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
GTIN-13 / EAN 4031026591865
Packaging 1 - Qty 500
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 1.32kg
Packaging 3 - Height (m) 0.210m
Packaging 3 - Length (m) 0.518m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0346
Packaging 3 - Weight (kg) 5.9kg
Packaging 3 - Width (m) 0.318m
Packaging 4 - Qty 80000
Packaging 4 - Type pallet
UNSPSC Key 39121703
