Fixing tie for hole (round)/for hole (hex), ∅1.5-35.0mm, natural, 500pcs.
Art.-No. 126-00150 | T50SOSSFT6.5E-MS-MD-PA66HS-NA 세부

  • One-piece fixing ties with cellular rubber disc
  • Especially suitable for door and tailgate harnesses used for car body applications
  • Made from PA66 heat-stabilised material
  • Cellular rubber disc minimises ingress of dust, dirt and splash water
Application The parts are mainly used in the automotive industry. This fastening solution is used to secure cable harnesses e.g. in car doors . We offer a variety of panel thicknesses and hole sizes to suit all kinds of application. The seal protects the interior and surrounding cables among other things from splash water.
Colour Natural (NA)
Fixation Method arrowhead
Identification Plate Position none
Key product features products for automatic tools
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION T50SOSSFT6.5E-MS-MD-PA66HS-NA
Pack Content 500pcs.
Package Content packed in bag
Product Family for round holes, sealed
Product Group 1-piece fixing ties with arrowhead, with disc
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50SOSSFT6.5E-MS-MD
Bundle Diameter max (metric) 35.0mm
Bundle ∅ min. 1.5mm
Disc ∅ 16.0mm
Length (L) 163.0mm
Min.Tensile Strength 180N
Thickness (T) 1.3mm
Width (W) 4.6mm
for Hole ∅ (FH) 6.25 - 6.75 mm, 6.1 - 6.6 mm (hexagonal)
for Panel Thickness min - max 0.7 - 1.6 mm
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026426570
UNSPSC Key 39121703
