Fixing tie for stud, inside serrated, ∅2.0-81.0mm, black, 500pcs.
Art.-No. 156-01020
| T80ISB5-PA66HS/PA66HIRHS-BK
|
세부
- Pre-assembled with cable tie and weld stud mounting base
- Quick and easy installation
- Head rotates into perfect position for installation
- 'Soft-push' design for tool-free installation
- Mushroom-shaped SBH handles insulation or a sound-deadening blanket
- SBS ideal for installation prior to attaching cable (i.e. no lateral tolerances required)
- SB5 allow lateral tolerance for fixing point
More products in this product group:
| Application | Primarily designed for use in the automotive industry, these parts can be used in a wide variety of applications where 5mm weld studs or 5mm ISO bolts are used and cables need to be bundled and secured |
| Colour | Black (BK) |
| Fixation Method | Weld Stud Fixing |
| Identification Plate Position | none |
| Material | Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | T80ISB5-PA66HS/PA66HIRHS-BK |
| Pack Content | 500pcs. |
| Package Content packed in | bag |
| Product Group | 2-Piece Fixing Ties for Weld , moveable |
| Tie Closure | plastic pawl |
| Type | T80ISB5 |
| Variant | Inside Serrated |
다운로드
|
|
|
| GTIN-13 / EAN | 4031026455341 |
| Packaging 1 - Height (m) | 0.14m |
| Packaging 1 - Length (m) | 0.42m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.02352m³ |
| Packaging 1 - Weight (kg) | 1.688815kg |
| Packaging 1 - Width (m) | 0.4m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 1500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 5.985445kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.249m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 18000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.199m³ |
| Packaging 4 - Weight (kg) | 92.832kg |
| Packaging 4 - Width (m) | 0.8m |
