Fixing tie for screw fixation, inside serrated, ∅10.0-23.0mm, black, 500pcs.
Art.-No. 156-01276 | X80RHDM6O-PA66HS/PA66HIRHS-BK 세부

Application Used in the automotive and truck industry for harness fixing in the engine body, these parts offer solutions in many other industrial applications with difficult environment.
Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
Colour Black (BK)
Fixation Method Weld Stud Fixing with metal inlay
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Mounting Screw Type M6 Screw
PART DESCRIPTION X80RHDM6O-PA66HS/PA66HIRHS-BK
Pack Content 500pcs.
Package Content packed in bag
Product Family HDM-Series
Product Group 2-piece fixing ties for heavy duty applications, for screws
Tie Closure plastic pawl
Type X80RHDM6O
Variant Inside Serrated
Bundle Diameter max (metric) 23.0mm
Bundle ∅ min. 10.0mm
Height (H) 15.5mm
Length (L) 200.0mm
Length (L2) 34.7mm
Min.Tensile Strength 355N
Width (W) 4.6mm
Width (W2) 26.0mm
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026487816
UNSPSC Key 39121717
