Mini cable channel, 90°, for hole (round), L=94.0mm, black, 300pcs.
Art.-No. 151-02418 | 90RA1-PA66HIRHSUV-BK | 세부

U-Shape channel provides three sides of protection for wire or bundle.

Angled channel allows specific guidance around corners or obstructions
U-Shape channel provides three sides of protection for wire or bundle
Protects against abrasion and other environmental factors
Types made from PPT20 material convince with a high operating temperature

More products in this product group:

Mini cable channel family >

Base Data

Application	The mini cable channel family allows a cost effective routing solution that provides protection and configurable routing. Pieces are modular and interchangeable, providing high levels of customization. Mini channels replace engineered channels which are costly to design and develop.
Colour	Black (BK)
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION	90RA1-PA66HIRHSUV-BK
Pack Content	300pcs.
Package Content packed in	carton
Product Family	Modular and interchangeable cable routing system
Product Group	Mini cable channel family
Type	90RA1

Product Dimensions

Angle	90
Length (L)	94.0mm
Length (L2)	94.0mm

Downloads

Specifications

CE Certification	No
CSA Certified	No
Flammability	UL 94 HB
Operating Temperature	-40 °C to +105 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	No
UL Recognized (US and Canada)	No
UV-Stabilised	Yes

Logistics and Packaging

GTIN-13 / EAN	4031026725703
Packaging 3 - Height (m)	0.2159m
Packaging 3 - Length (m)	0.606425m
Packaging 3 - Type	box
Packaging 3 - Volume (m³)	0.052m³
Packaging 3 - Width (m)	0.396875m

More Information

UNSPSC Key

39131600
