Connector clip, black, 100pcs.
Art.-No. 151-03215 | CCWPM712A-PA66HSW-BK 세부

Application The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry.
Colour Black (BK)
Material Polyamide 6.6, heat and UV-resistant (PA66HSW)
PART DESCRIPTION CCWPM712A-PA66HSW-BK
Pack Content 100pcs.
Package Content packed in bag
Product Family CCWPM712 for Oval Holes
Product Group Connector Clip with Arrowhead
Type CCWPM712A
Height (H) 15.0mm
Length (L) 19.1mm
Panel Thickness max. 4.8mm
Width (W) 23.5mm
for Hole ∅ (FH) 7.0 x 12.0 mm
for Panel Thickness min - max 1 - 4.8 mm
Flammability UL 94 V2
Operating Temperature -40 °C to +110 °C
GTIN-13 / EAN 4944387121797
UNSPSC Key 39121702
