01/03/2025

Corrugated tube clip, grey, 1700pcs.
Art.-No. 151-02693 | CDC25AH6.35-PP-GY |

Copied
Colour Grey (GY)
Fixation Method arrowhead
Key product features for convoluted tubes or with rib, lockable
Material Polypropylene (PP)
PART DESCRIPTION CDC25AH6.35-PP-GY
Pack Content 1700pcs.
Package Content packed in carton
Type CDC25AH6.35
⌀ (D2) 35.6mm
⌀ D 1.06"
⌀ D2 1.4"
Bundle Diameter max (metric) 25.0mm
Diameter (D) 27.0mm
Height (H) 81.2mm
Length (L) 64.0mm
Width (W) 10.2mm
for Hole ⌀ (FH) 6.35 mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free No
Hazardous Goods No
Operating Temperature -40 °C to +115 °C
ROHS compliant Yes
Specifications
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability.<BR>ReSource highlights HellermannTyton products that are made from reccled waste or from virgin materials with relatively lower carbon emissions. Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability.
ReSource highlights HellermannTyton products that are made from reccled waste or from virgin materials with relatively lower carbon emissions.
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised No
GTIN-13 / EAN 4031026725574
UNSPSC Key 31162906
