Bundling clip for hole (round), L=55.0mm, black, 500pcs.
Art.-No. 150-62698 | CLIP TCFT6-PA66HIRHS-BK |  세부

Anti rotation (Yes / No) NO
Colour Black (BK)
Fixation Method Fir Tree
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION CLIP TCFT6-PA66HIRHS-BK
Pack Content 500pcs.
Package Content packed in bag
Type CLIP TCFT6
Wings on clip base (Yes / No) YES
Bundling Bar Length 55.0mm
Disc ∅ 18.0mm
Fixing Hole Shape Circular
Height (H) 16.0mm
Length (L) 55.0mm
Length (L2) 9.0mm
Length of Fir Tree 7.5mm
Panel Thickness max. 0.8 - 3.0mm
for Hole ∅ (FH) 6.4 - 7.1 mm
for Panel Thickness min - max 0.8 - 3 mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026195100
Packaging 1 - Height (m) 0.065m
Packaging 1 - Length (m) 0.315m
Packaging 1 - Qty 500
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00563m³
Packaging 1 - Weight (kg) 0.654362kg
Packaging 1 - Width (m) 0.275m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 10000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083m³
Packaging 3 - Weight (kg) 13.69724kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.249m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.199m³
Packaging 4 - Weight (kg) 185.4kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121702
