Corrugated tube clip for hole (round), nom∅4.5mm, black, 6000pcs.
Art.-No. 151-02274 | CTCL4.5FT6LG-PA66HIRHS-BK |  세부

The tubing is clicked into the CTC clamp and is held firmly.

    • CTC clamps for a variety of nominal diameters
    • Fir tree foot part can be used for a variety of panel thicknesses
    • Suitable for use within threaded holes
    • Tube is guided accurately by clicking
    • Axial slipping is prevented by the inside profile of the clamp
    Show more
    Downloads
    Application CTC clamps are used for example in the automotive, harness making, electrical industry and wherever corrugated tubing has to be quickly and firmly fixed.
    Colour Black (BK)
    Fixation Method Fir Tree
    Key product features for convoluted tubes or with rib, reusable, removable, lockable
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CTCL4.5FT6LG-PA66HIRHS-BK
    Pack Content 6000pcs.
    Package Content packed in bag
    Product Family CTC-Series
    Product Group Fixing elements for corrugated tubing, with fir tree
    Type CTCL4.5FT6LG
    Attach to Ø NW4.5
    Bundle Diameter max (metric) 7.0mm
    Bundle ∅ min. 6.5mm
    Disc ∅ 16.0mm
    Height (H) 36.8mm
    Height (H2) 25.0mm
    Nominal ∅ 4.5mm
    Panel Thickness max. 0.75 - 6.0mm
    Width (W) 10.0mm
    for Hole ∅ (FH) 6.5 - 7.0 mm
    for Panel Thickness min - max 0.8 - 6 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026456560
    Packaging 1 - Height (m) 0.8m
    Packaging 1 - Length (m) 0.6m
    Packaging 1 - Qty 6000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.192m³
    Packaging 1 - Weight (kg) 6.581411kg
    Packaging 1 - Width (m) 0.4m
    Packaging 3 - Height (m) 0.204m
    Packaging 3 - Length (m) 0.591m
    Packaging 3 - Qty 6000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.048m³
    Packaging 3 - Weight (kg) 7.231411kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Height (m) 1.235m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 120000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.186m³
    Packaging 4 - Weight (kg) 165.62kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121702
