Blind plug, ∅6.1 - 6.7 mm, T=0.6 - 12.5mm, silver, 5000pcs.
Art.-No. 151-03251
| FT6.5SDLGBPLUG-PPS-SR
|
세부
- Easy assembly without the need of a tool
- Disc of the part covers the hole and minimises ingress of dust, dirt and water
- Standard geometry for example fir tree or arrowhead
More products in this product group:
| Application | Products were developed especially for the automotive industry. Application in trunks, doors, wheel housing and dash panels. Parts are even used for optical reasons. |
| Colour | Silver (SR) |
| Fixation Method | Fir Tree |
| Material | Polyphenylene Sulfide (PPS) |
| PART DESCRIPTION | FT6.5SDLGBPLUG-PPS-SR |
| Pack Content | 5000pcs. |
| Package Content packed in | bag |
| Product Group | Blind Plugs |
| Type | FT6.5SDLGBPLUG |
| Disc ∅ | 0.69" |
| Disc ∅ | 17mm |
| Fixing Hole Shape | Circular |
| Height (H) | 21.27mm |
| Length (L) | 21.27mm |
| Panel Thickness | 0.02 - 0.49" |
| Panel Thickness max. | 0.6 - 12.5mm |
| Panel Thickness max. (imperial) | 0.49" |
| Panel Thickness min. (imperial) | 0.02" |
| Width (W) | 7.80mm |
| for Hole ∅ (FH) | 6.1 - 6.7 mm |
| for Panel Thickness min - max | 0.6 - 12.5 mm |
