16/07/2024

Cable clip with pipe/tube holder, Dmin=8.0mm, Dmax=10.0mm, nom∅=9.0 mm, nom∅2=10.0 mm - 14.0 mm, black, 2500
Art.-No. 156-01859 | MOC9FLOC10-14-PA66HIRHSUV-BK | 세부

Base Data

Colour	Black (BK)
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION	MOC9FLOC10-14-PA66HIRHSUV-BK
Pack Content	2500
Package Content packed in	carton
Type	MOC9FLOC10-14
Variant	Clip to Clamp

Product Dimensions

Bundle Diameter Nom. (ND)	9.0 mm
Bundle Diameter Nom. 2 (ND2)	10.0 mm - 14.0 mm
Bundle Diameter max (metric)	10.0mm
Bundle ∅ 2 max.	14.0mm
Bundle ∅ 2 min.	10.0mm
Bundle ∅ min.	8.0mm
Depth (D)	12.0mm
Height (H)	27.4mm
Height (H2)	17.2mm
Length (L)	43.70mm
Length (L2)	25.0mm

Downloads

Specifications

CE Certification	No
CSA Certified	No
Flammability	UL 94 HB
Halogen-free	Yes
Operating Temperature	-40 °C to +110 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	No
UL Recognized (US and Canada)	No
UV-Stabilised	Yes

Logistics and Packaging

GTIN-13 / EAN	4031026715599
Packaging 1 - Weight (kg)	203.74kg

More Information

UNSPSC Key

39121702
