Cable clip with pipe/tube holder, Dmin=8.0mm, Dmax=10.0mm, nom∅=9.0 mm, nom∅2=15.0 mm - 19.0 mm
Art.-No. 156-01883 | MOC9FLOC15-19-PA66HIRHSUV-BK | 세부

Base Data

Colour	Black (BK)
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION	MOC9FLOC15-19-PA66HIRHSUV-BK
Pack Content	1000pcs.
Package Content packed in	carton
Type	MOC9FLOC15-19
Variant	Clip to Clamp

Product Dimensions

Bundle Diameter Nom. (ND)	9.0 mm
Bundle Diameter Nom. 2 (ND2)	15.0 mm - 19.0 mm
Bundle Diameter max (metric)	10.0mm
Bundle ∅ 2 max.	19.0mm
Bundle ∅ 2 min.	15.0mm
Bundle ∅ min.	8.0mm
Depth (D)	12.0mm
Height (H)	33.4mm
Height (H2)	17.2mm
Length (L)	44.40mm
Length (L2)	27.4mm

Downloads

Specifications

CE Certification	No
CSA Certified	No
Flammability	UL 94 HB
Halogen-free	Yes
Operating Temperature	-40 °C to +110 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	No
UL Recognized (US and Canada)	No
UV-Stabilised	Yes

Logistics and Packaging

GTIN-13 / EAN	4031026715711
Packaging 1 - Weight (kg)	204.16kg
Packaging 3 - Height (m)	0.212725m
Packaging 3 - Length (m)	0.51435m
Packaging 3 - Type	box
Packaging 3 - Volume (m³)	0.0347m³
Packaging 3 - Width (m)	0.3175m

More Information

UNSPSC Key

39121702
