Cable clip for adhesive use, Dmax=8.0mm
Art.-No. 151-00497 | RB8APT-PA66-BK |  세부

SolidTack Clip RB8APT with special adhesive.

    • Flat design to use in applications with limited space
    • One-piece self adhesive mount for quick and easy installation
    • Can be used without cable ties offering process optimization
    • Different sizes for various bundle diameters available
    • Cost effective with easy application on smooth, clean surfaces
    Show more
    Downloads
    Application RB-Series self adhesive mounts offer greater routing freedom and also reduce the risk of corrosion compared to screw fixing mounts. They are ideally suited for tool-free installation and can be re-opened and reused easily when cables need to be replaced. These mounts can be used without the need for additional cable ties. Offering process optimization in a variety of applications.
    Colour Black (BK)
    Fixation Method Pasting / Stick
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION RB8APT-PA66-BK
    Pack Content 100pcs.
    Package Content packed in bag
    Product Family RB-Series
    Product Group Mounts with cable clip, self-adhesive
    Type RB8APT
    Variant Closed
    Bundle Diameter max (metric) 8.0mm
    Height (H) 11.5mm
    Length (L) 25.0mm
    Width (W) 25.0mm
    Width (W2) 12.7mm
    Adhesive Acrylate with base of acrylic foam
    Adhesive Operating Temperature -40 °C to +90 °C
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    GTIN-13 / EAN 4031026286297
    Packaging 1 - Height (m) 0.025m
    Packaging 1 - Length (m) 0.215m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00113m³
    Packaging 1 - Weight (kg) 0.25708kg
    Packaging 1 - Width (m) 0.21m
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 10.22kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.249m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 48000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.199m³
    Packaging 4 - Weight (kg) 143.64kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121702
