23/12/2024

Cable tie mount to close hole/for edge protection, Wmax=4.6mm, T=25.4mm, ∅4.7 mm, black, 10pcs.
Art.-No. 151-29804 | MMB0-PA66STHS-BK | 세부

Base Data

Colour	Black (BK)
Fixation Method	with Fir Tree (Mounts)
For Ties	T18 - T50
Material	Polyamide 6.6, super tough, heat stabilized (PA66STHS)
PART DESCRIPTION	MMB0-PA66STHS-BK
Pack Content	10pcs.
Package Content packed in	bag
Type	MMB0

Product Dimensions


Height (H)	8.9mm
Length (L)	30.1mm
Max. Tie Width (G)	4.6mm
Panel Thickness	1.0"
Panel Thickness max.	25.4mm
Panel Thickness min. (imperial)	1.0"
Strap Width max. (G)	0.18"
Width (W)	9.0mm
Width of Fixing WF (metric)	5.9mm
for Hole ∅ (FH)	4.7 mm
for Panel Thickness min - max	25.4 - 25.4 mm

Downloads

RoHS datasheet

다운로드

Specifications

CE Certification	No
CSA Certified	No
Flammability	UL 94 HB
Operating Temperature	-40 °C to +105 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	No
UL Recognized (US and Canada)	No

Logistics and Packaging


Packaging 3 - Height (m)	0.212725m
Packaging 3 - Length (m)	0.51435m
Packaging 3 - Type	box
Packaging 3 - Volume (m³)	0.0347m³
Packaging 3 - Width (m)	0.3175m

More Information

UNSPSC Key

39121717
