19/11/2024

HG-LW1000-PA6-BK
Art.-No. 166-90199 | HG-LW1000-PA6-BK | 세부

Base Data

Colour	Black (BK)
Material	Polyamide 6 (PA6)
PART DESCRIPTION	HG-LW1000-PA6-BK
Pack Content	15.24m
Package Content packed in	reel
Pitch Type	coarse
Type	HG-LW1000

Product Dimensions

Bending Radius min. (BR)	2.17"
Bending Radius min. (R)	55mm
Inner Diameter D (Imperial)	1.12"
Inside Ø (ID)	28.1mm
Length (L)	15.2m
NW ∅	29mm
Nominal ∅	1"
Nominal ∅	34mm
Outside Ø (OD)	34.5mm
Outside ∅ (OD)	1.36"

Downloads

Specifications

CE Certification	No
CSA Certified	No
Flammability	EN IEC 61386
Halogen-free	Yes
Operating Temperature	-40 °C to +120 °C
Operating Temperature Moving	-20 °C to +100 °C
ROHS compliant	Yes
Self extinguishing	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	Yes
UL Recognized (US and Canada)	Yes
UL-File Number	E229161
UV-Stabilised	No

Logistics and Packaging

GTIN-13 / EAN

4031026464244

More Information

UNSPSC Key

39131601
