21/11/2024

HGL200-S-2000-PA66-BK
Art.-No. 166-90775 | HGL200-S-2000-PA66-BK 세부

Colour Black (BK)
Material Polyamide 6.6 (PA66)
PART DESCRIPTION HGL200-S-2000-PA66-BK
Pack Content 1pc.
Package Content packed in pack
Thread type NPT
Type HGL200-S-2000
Bore Diameter (Imperial) 2.09"
Bore Diameter (metric) 53
Length (L) 74.0mm
Nominal ∅ 2.63"
Nominal ∅ 67mm
Outside Ø (OD) 87.0mm
Outside ∅ (OD) 3.43"
Thread Length (TL) 20mm
Thread Length (TL) (Imperial) 0.79"
CE Certification No
CSA Certified No
Flammability UL 94 V2
Halogen-free Yes
IP-Rating IP68
Operating Temperature -50 °C to +135 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) Yes
UL Listed (US and Canada) Yes
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UL-File Number E247502
UV-Stabilised No
GTIN-13 / EAN 4031026572796
UNSPSC Key 39131601
