TCWM6-TYHC-WH
Art.-No. 598-00265 | TCWM6-TYHC-WH | 세부

Markers are kitted on each page so that any marker can be removed without affecting the other markers on the page.

Base Data

Application	150 Markers each T1, T2, T3
Colour	White (WH)
Colour of Print	Black (BK)
Material	Vinyl Cloth (TYHC)
PART DESCRIPTION	TCWM6-TYHC-WH
Pack Content	1pc.
Package Content packed in	book
Type	TCWM6

Product Dimensions

Bundle Diameter max (metric)	7.50mm
Bundle ∅ min.	3.40mm
Height (H)	28.1mm
Length (L)	41.27mm
Outside ∅ max (OD max.)	9.52mm
Outside ∅ max.	0.375"
Outside ∅ min.	0.1"
Outside ∅ min. (OD min.)	2.54mm
Width (W)	6.35mm

Downloads

Specifications

Adhesive	Rubber
Adhesive Operating Temperature	-40 °C to +120 °C
CE Certification	No
CSA Certified	No
Curing Temperature	from +10 °C
Halogen-free	No
Operating Temperature	-40 °C to +120 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	No
UL Recognized (US and Canada)	No
UV-Stabilised	No

Logistics and Packaging

GTIN-13 / EAN	4031026724553
Labels per Column	15
Labels per Row	3
Labels per Sheet	45

More Information

UNSPSC Key

39131507
