Cable tie mount for adhesive use, Wmax=2.7mm, black, 100pcs.
Art.-No. 151-00996 | MB2APT-PA66-BK |  Details

SolidTack Mount MB2APT with special adhesive.

    This product is not available anymore.

    Alternative product available

    • MB mounts with homogeneous system of acrylic adhesive
    • Very good initial adhesion, increases with time
    • Innovative fixing solution for high and low energy surfaces
    • Protection foil with finger lift for easy peel off
    Add to watchlist
    Downloads
    Application SolidTack MB Series mounts have a square design and are fairly common in areas like electrical cabinet, railway, aerospace, automotive and agriculture machinery. The premium self-adhesive bonds well on high and low-energy surfaces like plastics, metal, varnish or paint and is suitable for a wide range of applications.
    Colour Black (BK)
    Fixation Method Self-Adhesive
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION MB2APT-PA66-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family SolidTack-Series MB
    Product Group Cable tie mounts with high performance adhesive
    Short Description Cable Tie Mount 13x13 mm black
    Type MB2APT
    Height (H) 4.1mm
    Length (L) 13mm
    Strap Width max. (G) 2.7mm
    Weight/Unit 0.00052kg
    Width (W) 13mm
    Adhesive Acrylate with base of acrylic foam
    Adhesive Operating Temperature -30 °C to +120 °C
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2 (excluding adhesive)
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    Customs Number 39269097
    GTIN-13 / EAN 4031026449579
    Packaging 1 - Height (m) 0.1m
    Packaging 1 - Length (m) 0.22m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00528m³
    Packaging 1 - Weight (kg) 0.06098kg
    Packaging 1 - Width (m) 0.24m
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 25000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 16.065kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 300000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 213.84kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
    Show all
    Self-Adhesive cable tie mounts Self-Adhesive cable tie mounts

    Self-Adhesive cable tie mounts

    HellermannTyton self-adhesive cable tie mounts are perfectly suited for cable fastening on round and angled surfaces. To save time, reduce part diversity and weight.
