Cable tie mount for adhesive use, Wmax=4.4mm, ∅3.1 mm, black, 100pcs.
Артикулен 151-02244 | MB3APT-A-PA66-BK Подробности

  • MB mounts with homogeneous system of acrylic adhesive
  • Very good initial adhesion, increases with time
  • Innovative fixing solution for high and low energy surfaces
  • Protection foil with finger lift for easy peel off

Заявете вашата индивидуална оферта сега

Application SolidTack MB Series mounts have a square design and are fairly common in areas like electrical cabinet, railway, aerospace, automotive and agriculture machinery. The premium self-adhesive bonds well on high and low-energy surfaces like plastics, metal, varnish or paint and is suitable for a wide range of applications.
Colour Black (BK)
Fixation Method Screw Mounting and Adhesive
Material Polyamide 6.6 (PA66)
PART DESCRIPTION MB3APT-A-PA66-BK
Pack Cont. 100pcs.
Package Content packed in bag
Product Family SolidTack-Series MB
Product Group Cable tie mounts with high performance adhesive
Short Description Fixing part with adhesive 19x19 black
Type MB3APT-A
Fixing Hole Centres (F) 13.2mm
Height (H) 3.8mm
Length (L) 19.0mm
Strap Width max. (G) 4.4mm
Weight/Unit 0.001066kg
Width (W) 19.0mm
for Hole ∅ (FH) 3.1 mm
Adhesive Acrylate with base of acrylic foam
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2 (excluding adhesive)
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026604084
Packaging 1 - Height (m) 0.02m
Packaging 1 - Length (m) 0.28m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.0007
Packaging 1 - Weight (kg) 0.11211kg
Packaging 1 - Width (m) 0.125m
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 10000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 11.811kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 163.32kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000449
ETIM 8.0 Key EC000449
ETIM 9.0 Key EC000449
UNSPSC Key 39121717
