Cable tie outside serrated, 300.0x6.0mm, ∅10.0-80.0mm, black, 100pcs.
Артикулен 132-00020 | PFC300-PA66HS-BK Подробности

  • Both sides serrated cable tie
  • BHT-Series with round head for larger bearing area
  • BHT375 for centred position
  • CT- and LHT-Series with small squared head for restricted space areas
  • Tensioning with application tool
покажи повече

Заявете вашата индивидуална оферта сега

Application Using a single hole these 'chassis ties' are widely used in the automotive, truck and heavy equipment markets. Ideal for applications which have access to both sides of the hole - example truck frame rails.
Colour Black (BK)
Identification Plate Position none
Key product features for direct fixation
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION PFC300-PA66HS-BK
Pack Cont. 100pcs.
Package Content packed in bag
Product Family PFC Series
Product Group Cable ties for single hole application
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type PFC300
Variant Outside Serrated
Bundle Diameter max (metric) 80.0mm
Bundle ∅ 10.0-80.0mm
Bundle ∅ min. 10.0mm
Length (L) 300.0mm
Min.Tensile Strength 180N
Thickness (T) 1.5mm
Width (W) 6.0mm
Flammability UL 94 V2
Operating Temperature -40 °C to +105 °C
Country of Origin BR
GTIN-13 / EAN 7890176000170
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
