Fixing tie for hole (round), inside serrated, ∅1.0-45.0mm, grey, 1000pcs.
Артикулен 156-00235
| T50RFT8GSD-PA46-GY
|
Подробности
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
![](https://www.hellermanntyton.com/shared/speclogos/99595_All_Languages.jpg)
Заявете вашата индивидуална оферта сега
Оферта
Още продукти от тази продуктова група:
Application | Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines. |
Anti rotation (Yes / No) | NO |
Colour | Grey (GY) |
Fixation Method | Fir Tree |
Identification Plate Position | none |
Material | Polyamide 4.6 (PA46) |
No. of sides for tie attachment | 2 |
PART DESCRIPTION | T50RFT8GSD-PA46-GY |
Pack Cont. | 1000pcs. |
Package Content packed in | bag |
Product Family | Fir tree parts FT8 |
Product Group | 2-piece fixing ties with fir tree, with disc, for round holes |
Short Description | 2-Piece fixing tie 200x4.6 mm, with fir tree, PA66HS/PA66HIRHS, grey |
Tie Closure | plastic pawl |
Type | T50RFT8GSD |
Variant | Inside Serrated |
Bundle Diameter max (metric) | 45.0mm |
Bundle ∅ | 1.0-45.0mm |
Bundle ∅ min. | 1.0mm |
Disc ∅ | 16.0mm |
Fixing Hole Shape | Circular |
Height (H) | 17.2mm |
Length (L) | 202mm |
Length (L3) | 17.2mm |
Min Stud Length | 9.7mm |
Min Stud Length | 0.38" |
Min.Tensile Strength | 225N |
Panel Thickness max. | 1.5 - 4.0mm |
Thickness (T) | 1.2mm |
Weight/Unit | 0.002225kg |
Width (W) | 4.6mm |
Width (W3) | 6mm |
for Hole ∅ (FH) | 8.0 - 8.5 mm |
for Panel Thickness min - max | 0.1 - 0.2 " |
for Panel Thickness min - max | 1.5 - 4 mm |
|
|
Country of Origin | PL |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026267531 |
Packaging 1 - Height (m) | 0.15m |
Packaging 1 - Length (m) | 0.55m |
Packaging 1 - Qty | 1000 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.03919m³ |
Packaging 1 - Weight (kg) | 2.268597kg |
Packaging 1 - Width (m) | 0.475m |
Packaging 3 - Height (m) | 0.368m |
Packaging 3 - Length (m) | 0.584m |
Packaging 3 - Qty | 3000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.083m³ |
Packaging 3 - Weight (kg) | 7.250791kg |
Packaging 3 - Width (m) | 0.386m |
Packaging 4 - Height (m) | 1.249m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 36000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.199m³ |
Packaging 4 - Weight (kg) | 108.024kg |
Packaging 4 - Width (m) | 0.8m |
