Fixing tie for hole (oval), ∅1.5-25.0mm, black, 500pcs.
Артикулен 126-00256 | T60XSOSSFT62X122EMD-PA66HS-BK |  Подробности

Fixing bracket for an oval hole with a seal for protection against e.g. dust and splash water.

    • Easy to assemble without the need for a tool
    • Arrowhead simply locks into place
    • Disc adjusts the tie for pressures from various directions
    • Cable tie head always situated in defined position
    • Cellular rubber seal minimises access of dust and dirt
    • SFT versions for oval holes feature anti-twist protection
    покажи повече
    Добавяне към списъка с наблюдавани

    Заявете вашата индивидуална оферта сега

     Оферта
    Downloads
    Application The parts are mainly used in the automotive industry, e.g. for door harnesses.
    Colour Black (BK)
    Fixation Method Arrowhead for oval holes
    Identification Plate Position none
    Key product features sealed
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION T60XSOSSFT62X122EMD-PA66HS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family for oval holes, sealed
    Product Group 1-piece fixing ties with arrowhead, with disc
    Releasable Closure (Yes/No) No
    Short Description 1-piece fixing tie with arrowhead, with disc, sealed 133.6x5.5 mm black
    Tie Closure plastic pawl
    Type T60XSOSSFT62X122EMD
    Bundle Diameter max (metric) 25.0mm
    Bundle ∅ 1.5-25.0mm
    Bundle ∅ min. 1.5mm
    Disc ∅ 16.0 x 22.0mm
    Length (L) 133.6mm
    Min.Tensile Strength 300N
    Weight/Unit 0.002023kg
    Width (W) 5.5mm
    for Hole ∅ (FH) 6.2 x 12.2 mm
    for Panel Thickness min - max 0.7 - 2 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    Customs Number 39269097
    GTIN-13 / EAN 4031026519944
    Packaging 1 - Height (m) 0.11m
    Packaging 1 - Length (m) 0.285m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00878m³
    Packaging 1 - Weight (kg) 1.011501kg
    Packaging 1 - Width (m) 0.28m
    Packaging 3 - Height (m) 0.2m
    Packaging 3 - Length (m) 0.59m
    Packaging 3 - Qty 2000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.046m³
    Packaging 3 - Weight (kg) 4.866004kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.144m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 40000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.098m³
    Packaging 4 - Weight (kg) 118.32kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
