Cable clip with pipe/tube holder
Артикулен 156-01315
| DTC18x28-S-PA66HIRHS-BK
|
Подробности
- Fixing clip offers full 360° rotation
- For routing of two different bundles
- Simply clip on a wire or hose
- Suitable for post-installation of bundles
Заявете вашата индивидуална оферта сега
Оферта
Още продукти от тази продуктова група:
Application | These pipe clips interconnect two different bundles of goods, of various size and type. The mobility of the fixing tie provides even in difficult conditions, such as vibrations, a secure grip and protects the cables or bundles. |
Colour | Black (BK) |
Fixation Method | Omega Clip |
Key product features | rotatable, for multiple routing, removable |
Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
PART DESCRIPTION | DTC18x28-S-PA66HIRHS-BK |
Pack Cont. | 500pcs. |
Package Content packed in | bag |
Product Family | DTC - Double Tube Clip, rotatable 360° |
Product Group | Fixing elements for tubes and harnesses |
Short Description | Pipe clip 18x28-S high impact modified, heat stabilised, black |
Type | DTC18x28-S |
|
|
Country of Origin | CN |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026492117 |
Packaging 1 - Height (m) | 0.0001m |
Packaging 1 - Length (m) | 0.58m |
Packaging 1 - Qty | 500 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.00002m³ |
Packaging 1 - Weight (kg) | 2.087501kg |
Packaging 1 - Width (m) | 0.37m |
Packaging 3 - Height (m) | 0.36m |
Packaging 3 - Length (m) | 0.59m |
Packaging 3 - Qty | 2000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0828m³ |
Packaging 3 - Weight (kg) | 9.005004kg |
Packaging 3 - Width (m) | 0.39m |
Packaging 4 - Height (m) | 1.224m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 24000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.175m³ |
Packaging 4 - Weight (kg) | 129.06kg |
Packaging 4 - Width (m) | 0.8m |
