Bundling clip for hole (round), L=55.0mm, black, 2000pcs.
Артикулен 151-08101 | LRJ1-PA6-BK Подробности

Заявете вашата индивидуална оферта сега

Anti rotation (Yes / No) NO
Colour Black (BK)
Fixation Method arrowhead
Material Polyamide 6 (PA6)
PART DESCRIPTION LRJ1-PA6-BK
Pack Cont. 2000pcs.
Package Content packed in bag
Product Group Bundling Clips with Arrowhead
Short Description Bundling Clip, round hole 6.2 - 6.7 mm, arrow head, PA6, black
Type LRJ1
Wings on clip base (Yes / No) YES
Bundling Bar Length 55.0mm
Disc ∅ 16.0mm
Fixing Hole Shape Circular
Height (H) 6.5mm
Length (L) 55.0mm
Panel Thickness max. 0.6 - 2.0mm
Weight/Unit 0.001247kg
Width (W) 8.0mm
Width (W2) 10.0mm
for Hole ∅ (FH) 6.2 - 6.7 mm
for Panel Thickness min - max 0.6 - 2 mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +85 °C, (+105 °C, 500 h)
ROHS compliant Yes
Specifications
Country of Origin FR
Customs Number 39269097
GTIN-13 / EAN 4031026239002
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.2m
Packaging 3 - Length (m) 0.4m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.024
Packaging 3 - Weight (kg) 2.914kg
Packaging 3 - Width (m) 0.3m
Packaging 4 - Height (m) 1.144m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 80000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.098
Packaging 4 - Weight (kg) 137.56kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121717
