Accessory for IWS, grey, 20pcs. (CTCC-IWS50-MB65)
Артикулен 169-22003
| CTCC-IWS50-MB65-PA66/6HIRHS-GY
|
Подробности
- Compatible with the IWS corrugated tubings
- Safe and fixe hold of the corrugated tubing
- Easy closing and reopening of the lid
- Cable tie holder on both sides
- Pre-fixation of the corrugated tubing in open status
- Can be fixed with screws and matched to the mounting rails of the control cabinets
- Additional laying - a ground cable on the corrugated tubings possible (through recess in the cover)
- Self-extinguishing according to UL94 HB
Заявете вашата индивидуална оферта сега
Оферта
Още продукти от тази продуктова група:
| Application | CTCC IWS corrugated tubing holders are used in the control cabinet for fastening and guiding. |
| Colour | Grey (GY) |
| Fixation Method | screw-hole |
| Material | Polyamide 6.6/6, high impact modified, heat stabilised (PA66/6HIRHS) |
| PART DESCRIPTION | CTCC-IWS50-MB65-PA66/6HIRHS-GY |
| Pack Cont. | 20pcs. |
| Package Content packed in | bag |
| Product Family | CTCC IWS corrugated tubing holder |
| Product Group | Corrugated tubing holder |
| Short Description | CTCC IWS corrugated tubing holders |
| Type | CTCC-IWS50-MB65 |
Изтегли
|
|
|
| Country of Origin | DE |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026638331 |
| Packaging 1 - Height (m) | 0.05m |
| Packaging 1 - Length (m) | 0.395m |
| Packaging 1 - Qty | 20 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00889m³ |
| Packaging 1 - Weight (kg) | 0.550335kg |
| Packaging 1 - Width (m) | 0.45m |
| Packaging 3 - Height (m) | 0.538m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 320 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.1213m³ |
| Packaging 3 - Weight (kg) | 9.90536kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.22m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 2560 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.171m³ |
| Packaging 4 - Weight (kg) | 100.226kg |
| Packaging 4 - Width (m) | 0.8m |
