Fixing tie for edge, ∅3.0-42.0mm, black, 1000pcs.
Cikkszám 156-04014
| T50ROSEC1-3RO90SO3-PA66HS/PA66HIRHS-BK
|
Részletek
- Pre-assembled 2-piece fixing tie with EdgeClip
- Easy to assemble by hand
- Cable tie head can be moved after bundling
- For edges of 1 – 2.5 mm or 1 – 3 mm
- Can be rotated to the desired position
Kérje egyedi ajánlatát most
Ajánlatkérés
More products in this product group:
| Application | These cable ties and EdgeClip assemblies are ideal for use where holes are not acceptable or or where adhesives will fail due to temperature problems. These assemblies are widely used for fixing and bundling cables, pipes and hoses within the automotive industry, harness making, panel buidling and electrical industry. |
| Colour | Black (BK) |
| Description | These EdgeClips are also mounted simply by pushing them onto an edge. A twistable EdgeClip is the ideal solution whenever flexible routing of cable bundles is required. The cable route can even be modified post-installation. The clips are available in 90° and 360° models for use with different types of cable tie. On the CBT30MR the bundle runs at the side of the clip, on the CBTO50R it runs over the centre of the clip. |
| Fixation Method | Edge Clips with tie |
| Identification Plate Position | none |
| Key product features | rotatable |
| Material | Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | T50ROSEC1-3RO90SO3-PA66HS/PA66HIRHS-BK |
| Pack Cont. | 1000pcs. |
| Package Content packed in | bag |
| Product Family | EdgeClip-Series, twistable |
| Product Group | 2-piece fixing ties for edges |
| Type | T50ROSEC1-3RO90SO3 |
| Bundle Diameter max (metric) | 42.0mm |
| Bundle ∅ | 3.0-42.0mm |
| Bundle ∅ min. | 3.0mm |
| Disc ∅ | 12.0mm |
| Height (H) | 18.5mm |
| Length (L) | 200.0mm |
| Min.Tensile Strength | 225N |
| Offset Length | 3.0mm |
| Panel Thickness max. | 1.0 - 3.0mm |
| Thickness (T) | 1.3mm |
| Weight/Unit | 0.003025kg |
| Width (W) | 4.6mm |
| for Panel Thickness min - max | 1 - 3 mm |
Letöltés
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026663852 |
| Packaging 1 - Height (m) | 0.18m |
| Packaging 1 - Length (m) | 0.55m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.04703m³ |
| Packaging 1 - Weight (kg) | 3.068597kg |
| Packaging 1 - Width (m) | 0.475m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Type | pallet |
| Packaging 4 - Width (m) | 0.8m |
