Fixing tie for cable bundles, outside serrated, ∅1.6-35.0mm, black, 500pcs.
Cikkszám 148-00091
| T50SOSWB4.3E-PA66HS-BK
|
Részletek
- Cable tie head always in defined position
- Easy to close by simply pressing the cover
- Firm sit as a variation of sizes for different wires is available
- Suitable for post-installation of bundles
Kérje egyedi ajánlatát most
Ajánlatkérés
More products in this product group:
Colour | Black (BK) |
Identification Plate Position | none |
Key product features | lockable |
Material | Polyamide 6.6, heat stabilised (PA66HS) |
PART DESCRIPTION | T50SOSWB4.3E-PA66HS-BK |
Pack Cont. | 500pcs. |
Package Content packed in | bag |
Product Family | for post-installation of bundles |
Product Group | 1-piece fixing ties with wire clip |
Releasable Closure (Yes/No) | No |
Tie Closure | plastic pawl |
Type | T50SOSWB4.3E |
Attach to Diameter | 0.17 " |
Attach to Ø | 4.3 |
Bundle Diameter max (metric) | 35.0mm |
Bundle ∅ | 1.6-35.0mm |
Bundle ∅ min. | 1.6mm |
Length (L) | 150.0mm |
Min.Tensile Strength | 225N |
Nominal ∅ | 0.19" |
Nominal ∅ | 4.3mm |
Thickness (T) | 1.3 |
Weight/Unit | 0.002018kg |
Width (W) | 4.6mm |
Wire Size Range (in²) | 0.168 - 0.173" |
Wire Size Range (mm²) | 4.27 - 4.4mm |
∅ D | 0.17" |
|
|
Country of Origin | DE |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026406121 |
Packaging 1 - Height (m) | 0.07m |
Packaging 1 - Length (m) | 0.395m |
Packaging 1 - Qty | 500 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.01244m³ |
Packaging 1 - Weight (kg) | 1.038135kg |
Packaging 1 - Width (m) | 0.45m |
Packaging 3 - Height (m) | 0.368m |
Packaging 3 - Length (m) | 0.584m |
Packaging 3 - Qty | 4000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.083m³ |
Packaging 3 - Weight (kg) | 9.12508kg |
Packaging 3 - Width (m) | 0.386m |
Packaging 4 - Height (m) | 1.248m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 48000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.198m³ |
Packaging 4 - Weight (kg) | 130.488kg |
Packaging 4 - Width (m) | 0.8m |
