Connector clip for hole (round), black, 1000pcs.
Cikkszám 155-36002
| STECKERHALTER SITZ-PA66HIRHS-BK
|
Részletek
- Connector easily installed by simply pushing into place
- Connection can be released (non-destructive)
- One fir tree foot part can be used for a variety of panel thicknesses
- Disc covers the hole to prevent dirt and water gaining access
- For twist protection: Variants with additional stick or for oval holes
Kérje egyedi ajánlatát most
Ajánlatkérés
More products in this product group:
| Application | The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry. |
| Colour | Black (BK) |
| Fixation Method | Fir tree for round holes |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | STECKERHALTER SITZ-PA66HIRHS-BK |
| Pack Cont. | 1000pcs. |
| Package Content packed in | pcs. |
| Product Group | Connector Clips for round holes |
| Short Description | Connector Clip, round hole 6.5 - 7.0 mm, fir tree, high impact modified, heat stabilised, black |
| Type | STECKERHALTER SITZ |
| Type of connection | AMP |
Letöltés
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | No |
|
|
|
| Country of Origin | DE |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026219134 |
| Packaging 1 - Height (m) | 0.05m |
| Packaging 1 - Length (m) | 0.28m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00511m³ |
| Packaging 1 - Weight (kg) | 1.238993kg |
| Packaging 1 - Width (m) | 0.365m |
| Packaging 3 - Height (m) | 0.204m |
| Packaging 3 - Length (m) | 0.591m |
| Packaging 3 - Qty | 8000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.048m³ |
| Packaging 3 - Weight (kg) | 10.561944kg |
| Packaging 3 - Width (m) | 0.398m |
| Packaging 4 - Height (m) | 1.164m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 160000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.117m³ |
| Packaging 4 - Weight (kg) | 232.24kg |
| Packaging 4 - Width (m) | 0.8m |
