Connector clip for hole (round), black, 1000pcs.
Cikkszám 151-00934 | YCCSFT6.5PT0.8-1.5MD-PA66HIRHS-BK Részletek

  • Connector easily installed by simply pushing into place
  • Connection can be released (non-destructive)
  • Arrowhead locks into place for secure fixing at all times

Kérje egyedi ajánlatát most

Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION YCCSFT6.5PT0.8-1.5MD-PA66HIRHS-BK
Pack Cont. 1000pcs.
Package Content packed in bag
Type YCCSFT6.5PT0.8-1.5MD
Height (H) 16.5mm
Length (L) 28.5mm
Weight/Unit 0.001053kg
Width (W) 22.0mm
for Hole ∅ (FH) 6.3 - 6.7 mm
for Panel Thickness min - max 0.8 - 1.5 mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
ROHS compliant Yes
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026438085
Packaging 1 - Height (m) 0.075m
Packaging 1 - Length (m) 0.21m
Packaging 1 - Qty 1000
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00536
Packaging 1 - Weight (kg) 1.082135kg
Packaging 1 - Width (m) 0.34m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 10000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 12.11135kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.249m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.199
Packaging 4 - Weight (kg) 166.32kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000449
ETIM 8.0 Key EC000449
ETIM 9.0 Key EC000449
UNSPSC Key 39121702
