Cable tie inside serrated, 383.5x12.7mm, ∅9.5-105.0mm, black, 300pcs.
Art.-No. 111-12302
| WSR-PA66HIRHSUV-BK
|
세부
- Wide strap is designed to minimize pinching of soft hoses and convoluted tubing
- Low profile head
- Clamping rails on the bottom of head to increase grip on round bundles
- Accommodates a large range of bundle diameters: 9.5mm - 104.7mm
- Flexible strap
- Bent tip for quick insertion into mounts
More products in this product group:
| Application | The very flexible wide-strap cable tie is used in heavy-duty applications where limited room is offered for the application. It is therefore a valued product in all areas of mass transit, as well as the construction and automotive industries. |
| Colour | Black (BK) |
| Identification Plate Position | none |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| PART DESCRIPTION | WSR-PA66HIRHSUV-BK |
| Pack Content | 300pcs. |
| Package Content packed in | bag |
| Product Family | WS-Series for heavy duty applications |
| Product Group | Cable ties for hose and convoluted tubing |
| Releasable Closure (Yes/No) | No |
| Tie Closure | plastic pawl |
| Type | WSR |
| Variant | Inside Serrated |
다운로드
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Nato number | 5975-12-394-6945 |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | Yes |
|
|
|
| GTIN-13 / EAN | 4031026311661 |
| Packaging 1 - Height (m) | 0.03m |
| Packaging 1 - Length (m) | 0.5m |
| Packaging 1 - Qty | 300 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0018m³ |
| Packaging 1 - Weight (kg) | 0.660001kg |
| Packaging 1 - Width (m) | 0.12m |
| Packaging 3 - Height (m) | 0.212725m |
| Packaging 3 - Length (m) | 0.51435m |
| Packaging 3 - Qty | 1200 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0347m³ |
| Packaging 3 - Weight (kg) | 9.47kg |
| Packaging 3 - Width (m) | 0.3175m |
| Packaging 4 - Height (m) | 1.22m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 48000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.171m³ |
| Packaging 4 - Weight (kg) | 86.0kg |
| Packaging 4 - Width (m) | 0.8m |
