Fixing tie with pipe/tube holder, ∅50.0mm, black, 500pcs.
Art.-No. 156-00943 | T50RIAHC4TCR-PA66HS/PA66HIRHS-BK | 세부

2-piece fixing tie, 360° rotatable, a cable tie in combination with an AHC to route and fix harnesses.

More products in this product group:

2-piece fixing ties with automatic harness clip >

Base Data

Application	Offering a simple and secure method of attaching cables together. Originally designed for the automotive industry, these products are used in a wide range of applications.
Application Tool	ProCut 9 no battery, MK3PNSP2, MK3SP, MK7HT, MK7P, MK20, MK21, EVO7SP, EVO7i, EVO7iSP, EVO9, EVO9i
Colour	Black (BK)
Identification Plate Position	none
Key product features	rotatable, for multiple routing, removable
Material	Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION	T50RIAHC4TCR-PA66HS/PA66HIRHS-BK
Pack Content	500pcs.
Package Content packed in	bag
Product Family	IAHC-Series
Product Group	2-piece fixing ties with automatic harness clip
Type	T50RIAHC4TCR

Product Dimensions

Attach to Ø	27.0 - 36.0
Bundle Diameter max (metric)	50.0mm

Downloads

Specifications

ROHS compliant	Yes
Specifications

Logistics and Packaging

GTIN-13 / EAN

4031026447759

More Information

UNSPSC Key

39121717
