05/11/2024

Fixing tie with pipe/tube holder, ∅50.0mm, black, 500pcs.
Art.-No. 156-00944 | T50RIAHC5TCR-PA66HS/PA66HIRHS-BK | 세부

2-piece fixing tie, 360° rotatable, a cable tie in combination with an AHC to route and fix harnesses.

More products in this product group:

2-piece fixing ties with automatic harness clip >

Base Data

Application	Offering a simple and secure method of attaching cables together. Originally designed for the automotive industry, these products are used in a wide range of applications.
Application Tool	MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
Colour	Black (BK)
Identification Plate Position	none
Key product features	rotatable, for multiple routing, removable
Material	Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION	T50RIAHC5TCR-PA66HS/PA66HIRHS-BK
Pack Content	500pcs.
Package Content packed in	bag
Product Family	IAHC-Series
Product Group	2-piece fixing ties with automatic harness clip
Type	T50RIAHC5TCR

Product Dimensions

Attach to Ø	35.0 - 45.0
Bundle Diameter max (metric)	50.0mm
Length (L)	200.0mm
Min.Tensile Strength	225N
Thickness (T)	1.2mm
Width (W)	4.6mm

Downloads

Specifications

ROHS compliant	Yes
Specifications

Logistics and Packaging

GTIN-13 / EAN

4031026447766

More Information

UNSPSC Key

39121717

Accessories

Similar products

T50RIAHC1TSET 156-00970
2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
T50RIAHC2TSET 156-00912
2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
T50RIAHC3TSET 156-00989
2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
T50RIAHC4TSET 156-00126
2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
T50RIAHC5TSET 156-00127
2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
T60SOSSFT712S-EIAHC 156-01585
2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
IAHC3AH 151-00378
Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, connectable
IAHC4AH 151-00382
Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, interconnectable
IAHC3BH 151-00380
Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, interconnectable
IAHC3CH 151-00381
Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, interconnectable
IAHC5BH 151-00384
Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, interconnectable
IAHC4CH 151-00383
Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, interconnectable
IAHC1T 151-02883
Fixing elements for tubes and harnesses with automatic locking feature, connectable
IAHC5T 151-00195
Fixing elements for tubes and harnesses with automatic locking feature, connectable
T50RIAHC1TICR 156-03377
2-piece fixing ties with automatic harness clip
