Fixing tie for hole (round), ∅2-50.0mm, black, 2000pcs.
Art.-No. 156-02545 | T50ROS25BCCSRAH-PA66HIRHSUV/TPE-BK | 세부

More products in this product group:

Application	The parts are mainly used in the automotive industry. This fastening solution is used to secure cable harnesses e.g. in car doors. We offer a variety of panel thicknesses and hole sizes to suit all kinds of application. The seal protects the interior and surrounding cables among other things from splash water.
Colour	Black (BK)
Fixation Method	arrowhead
Identification Plate Position	none
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Thermoplastic Elastomer (TPE)
PART DESCRIPTION	T50ROS25BCCSRAH-PA66HIRHSUV/TPE-BK
Pack Content	2000pcs.
Package Content packed in	bag
Product Family	for round holes, sealed
Product Group	2-piece fixing ties with arrowhead, with disc
Tie Closure	plastic pawl
Type	T50ROS25BCCSRAH


Bundle Diameter max (metric)	50.0mm
Bundle ∅ min.	2mm
Height (H)	17.9mm
Length (L)	228mm
Min.Tensile Strength	222N
Offset Length	25.0mm
Panel Thickness	0.02 - 0.04"
Panel Thickness max.	0.6 - 1.1mm
Panel Thickness max. (imperial)	0.04"
Panel Thickness min. (imperial)	0.02"
Width (W)	28.4mm
for Hole ∅ (FH)	6.35 mm (hexagonal), 6.5 mm
for Panel Thickness min - max	0.6 - 1.1 mm
for Panel Thickness min - max	0 - 0 "
