Fixing tie for hole (round), ∅2.0-50.0mm, black, 1000Bag
Art.-No. 157-00199
| T50ROSFT612.5SOVC-PA66HIRHSUV-BK
|
세부
- Bundling and fixing solution
- Ideal combination of materials and design
- Different positions of the fixing anchor are available to fit installation space
More products in this product group:
Colour | Black (BK) |
Fixation Method | Fir tree for round holes |
Identification Plate Position | none |
Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
PART DESCRIPTION | T50ROSFT612.5SOVC-PA66HIRHSUV-BK |
Pack Content | 1000Bag |
Package Content packed in | carton |
Product Family | With offset 12.5 and 25.0 mm |
Product Group | 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes |
Releasable Closure (Yes/No) | No |
Type | T50ROSFT612.5SOVC |
Bundle Diameter max (metric) | 50.0mm |
Bundle ∅ min. | 2.0mm |
Disc ∅ | 0.66" |
Length (L2) | 12.5mm |
Min.Tensile Strength | 225N |
Offset Length | 12.5mm |
Panel Thickness | 0.02 - 0.20" |
Panel Thickness max. | 0.6 - 5.0mm |
Panel Thickness max. (imperial) | 0.20" |
Panel Thickness min. (imperial) | 0.02" |
for Hole ∅ (FH) | 6.1 - 6.9 mm |
for Panel Thickness min - max | 0.6 - 5 mm |
for Panel Thickness min - max | 0 - 0.2 " |
|
|
GTIN-13 / EAN | 4031026487977 |
Packaging 1 - Height (m) | 0.13m |
Packaging 1 - Length (m) | 0.58m |
Packaging 1 - Qty | 1000 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.02262m³ |
Packaging 1 - Weight (kg) | 2.461001kg |
Packaging 1 - Width (m) | 0.3m |
Packaging 3 - Height (m) | 0.37465m |
Packaging 3 - Length (m) | 0.59055m |
Packaging 3 - Qty | 3000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0646m³ |
Packaging 3 - Weight (kg) | 8.96kg |
Packaging 3 - Width (m) | 0.2921m |
Packaging 4 - Height (m) | 1.27m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 36000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.219m³ |
Packaging 4 - Weight (kg) | 118.356kg |
Packaging 4 - Width (m) | 0.8m |
